Basic Weighing, Parts Counting, Percent Weighing
Backlit Liquid Crystal Display (LCD)
AC adapter (included)
RS232 (one port included)
ABS top housing, removable stainless steel pan, removable glass draftshield with sliding top door, integrated weigh-below-hook, security bracket, calibration lock
User-selectable environmental filters and brightness settings, auto-tare, auto-dim, user-selectable span calibration points, software lockout and reset menu, userselectable communication settings and data print options, user-definable project and user IDs, software overload/underload indicator, stability indicator
| Maximum Capacity |
420 g |
| Readability |
0.001 g |
| Pan Size |
4.7 in (120 mm) |
| Internal Calibration |
InCal™ - Semi Automatic |
| Draftshield |
Included |
| Auxiliary Display Model |
Available as an Accessory |
| Battery Life |
Not Applicable |
| Communication |
RS232 |
| Dimensions |
12.5 in x 11.9 in x 7.9 in (317 mm x 303 mm x 201 mm) (LxHxW) |
| Display |
LCD with backlight |
| In-Use Cover |
Included |
| Legal for Trade |
No |
| Linearity ± |
0.002 g |
| Net Weight |
10 lb (4.5 kg) |
| Pan Construction |
Stainless Steel |
| Power |
AC Adapter (Included) |
| Repeatability, typical |
0.001 g |
| Stabilization Time |
2 s |
| Tare Range |
To capacity by subtraction |
| Units of Measurement |
Milligram; Pennyweight; Ounce Troy; Newton; Taiwan Tael; Gram; Kilogram; Grain; Pound; Ounce; Carat; Custom |
| Working Environment |
operability guaranteed between 41°F and 104°F; 50°F – 86°F, 80%RH, non-condensing (operability guaranteed between 5°C and 40°C; 10°C – 30°C, 80%RH, non-condensing) |
