Meter's Technical Specs
|
|
pH
|
Range
|
-2.00 to 16.00 pH
|
|
Resolution
|
0.01/0.1 pH
|
|
Accuracy
|
±0.01 pH ±1 digit
|
|
Calibration Points
|
Automatic 1 to 3 points (recognizes 5 types: 7.00, 4.00, 10.01, 1.68, 12.46)
|
|
Temperature Compensation
|
Auto Temperature Compensation
0 to 50°C (32 to 122°F)
|
|
ORP (mV)
|
Range
|
±1000 mV
|
|
Resolution
|
1 mV
|
|
Accuracy
|
±0.2% F.S
|
|
Temp.
|
Range
|
0 to 50°C (32 to 122°F)
|
|
Resolution
|
0.1°C
|
|
Accuracy
|
±0.5°C
|
|
LCD
|
3-Color Backlit LCD, 180° Viewing Angle
Blue: Measurement Mode; Green: Calibration Mode;
Red: Heads-Up Mode
|
|
Reading Lock
|
HOLD
|
|
Stable Reading Indication
|
Smiley Face icon
|
|
Low-Battery Warning
|
Battery icon flashing, reminder of battery replacement
|
|
Self-Diagnosis
|
Yes
|
|
Heads-Up Function
|
Yes
|
|
Auto. Power-Off
|
Yes, auto power-off in 8 minutes without operation
|
|
Waterproof Rating
|
IP67; Floatable
|
|
Power
|
DC3V, AAA batteries*4
|
|
Battery Life
|
Continuous operation up to 2000 hours
|
|
Dimensions& Weight
|
Tester: (40*40*220) mm/ 143g; With case_(255*210*50) mm/ 710g
|
|
Electrode's Technical Specs
|
|
Application
|
Solid and semi-solid pH Test: cheese, meat, fruit, sushi rice, bread, solid culture medium, soil, etc.;
Regular water solution testing
|
|
Shape of glass membrane
|
Spear
|
|
Replaceable
|
Yes
|
|
Temperature sensor
|
Yes
|
|
Junction
|
Double junction without diaphragm
|
|
Reference Electrode
|
Long-Life Reference System
|
|
Electrolyte
|
Polymer Gel
|
|
Range
|
0 to 14 pH
|
|
Temperature Range
|
0 to 50°C (32 to 122°F)
|
